The Scale Gravel was put on this planet for going on adventures with attitude. Designed to go the distance over any and all types of terrain, the Scale Gravel is lightweight with agile handling and features multiple mounting options.
Please note that bike specifications are subject to change without prior notice.
Code:
Electric Bikes
| Motor Torque | 120nm with Bosch Performance Upgrade 2.0 |
|---|---|
| Frame | Scale Carbon HMF, Adjustable head angle, Syncros Cable Integration System, Advanced Shock & Standing Damping System, BB92, UDH Interface, 12x148mm with 55mm Chainline |
| Fork | Scale Rigid HMF, Postmount Disc Standard, Tapered Carbon steerer |
| Headset | Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Stem | Syncros XC 2.0, Syncros Cable Integration System, -12° rise, 6061 Alloy, 31.8mm, 1 1/8" |
| Grips | Syncros Performance XC lock-on grips |
| Gear Shifters | SRAM AXS Pod Controller |
| Rear Derailleur | SRAM S1000 Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System |
| Chain | SRAM CN Eagle 70 Transmission |
| Cassette/Freewheel | SRAM Eagle XS 1270 V2 Transmission 10-52 |
| Chainset | SRAM Eagle 70 Transmission, DUB, 55mm CL, 34T |
| Number of Gears | 12 |
| Brakes | SRAM DB6 4-Piston Disc |
| Front Hub | Formula CL-811, 15x110mm |
| Rear Hub | Formula CL-3248, 12x148mm |
| Rims | Syncros X-28, 28H, Tubeless ready |
| Tyres | Maxxis Aspen, 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO / Maxxis Aspen, 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO |
| Saddle | Syncros Belcarra V2.0 Cut Out, CRMO rails |
| Seat Post | Syncros Duncan 2.0, 10mm offset, 31.6x400mm |
